Product Specifications
General
Manufacturer
Diamond Products - Core Cut
Model
CC1025E-8
Power & Performance
Engine/Motor
Baldor Electric Motor
Horse Power
2.5 HP
Power Source
Electric
Power Supply
110V/230V - 1PH
Torque
Not specified
Self Propelled Drive
Not specified
Speed
6100 RPM
Transmission
Not specified
Electric Start
Not specified
Low Oil Alert
Not applicable
Tach/Hour Meter
Not specified
Cutting Specifications
Max Blade Size
8"
Max Blade Cutting Depth
2.25"
Blade Mount
1" or 5/8" arbor
Cut Direction
Up Cut
Blade Shaft RPM
6100
Blade Arbor Size
1" or 5/8"
Blade Width
Not specified
Depth Adjustment
Adjustable blade alignment
Blade Flange
Not specified
Blade Included
Not specified
Maneuverability
Wheel Material
Easy to maneuver push drive
Front Wheels
3" x 2" x 0.75"
Rear Wheels
5" x 2" x 0.75"
Straight Cut Wheels
Not specified
Transport
Ultra lightweight design for easy handling
Weight/Dimensions
Dry Weight (lbs)
75
Operating Weight (lbs)
Not specified
Length
23.5"
Width
14.5"
Height
34.5"
Safety and Compliance
Dust Suppression
Not specified
OSHA Compliant
Not specified
Warranty
Product Warranty
Not specified
Engine Warranty
Not specified
Additional Features
Handle Design
Center cut design for easier straight cuts
Battery Access
Not applicable
