Product Specification
Specifications
Service & Maintenance Parts
ACCESSORIES 26 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1BATTERY CHARGER | 967964901 | 1 | QC330 EU | ||
| 1BATTERY CHARGER | 967965006 | 1 | QC500 SZ | ||
| 1BATTERY CHARGER | 967965005 | 1 | QC500 AU/NZ | ||
| 1BATTERY CHARGER | 967965002 | 1 | QC500 UK | ||
| 1BATTERY CHARGER | 967965001 | 1 | QC500 EU | ||
| 1BATTERY CHARGER | 967965003 | 1 | QC500 US |
Regular price
$0.00
Regular price
|
|
| 1BATTERY CHARGER | 967965004 | 1 | QC500 JP | ||
| 1BATTERY CHARGER | 967964906 | 1 | QC330 SZ | ||
| 1BATTERY CHARGER | 967964907 | 1 | QC330 BR | ||
| 1BATTERY CHARGER | 967964905 | 1 | QC330 AU/NZ | ||
| 1BATTERY CHARGER | 967964904 | 1 | QC330 JP | ||
| 1BATTERY CHARGER | 967964902 | 1 | QC330 UK | ||
| 1BATTERY CHARGER | 967964903 | 1 | QC330 US | ||
| 2BATTERY | 967964301 | 1 | Bli300 RoW | ||
| 2BATTERY | 967964302 | 1 | Bli300 US/CA |
Regular price
$369.00
Regular price
|
|
| 2BATTERY | 967964102 | 1 | BLi200 US/CA |
Regular price
$227.70
Regular price
|
|
| 2BATTERY | 967964101 | 1 | BLi200 RoW | ||
| 3KEY | 531140952 | 1 | 32mm |
Regular price
$44.29
Regular price
|
|
| 4KEY | 531140951 | 1 | 24mm |
Regular price
$44.29
Regular price
|
|
| 5BOX | 534113901 | 1 | |||
| 6BY TC PARTNAME LINK | 581295001 | 1 | QC330/QC500-CORD 330W/500W-AU/NZ | ||
| 6MAINS CABLE | 581294901 | 1 | QC330/QC500-CORD 330W/500W-JP | ||
| 6MAINS CABLE | 578081901 | 1 | QC330/QC500-CORD 330W/500W, 220V-EU | ||
| 6CABLE | 579130601 | 1 | QC330/QC500-CORD 330W/500W, 220V-UK | ||
| 6CABLE | 579130401 | 1 | QC330/QC500-CORD 330W/500W-US |
Regular price
$39.19
Regular price
|
|
| 6WIRING ASSY | 582639701 | 1 | QC330/QC500-CORD 330W/500W-SZ |
ACCESSORIES 37 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1SLURRY RINGS | 593563001 | 1 | WSR 100 mm | ||
| 1SLURRY RINGS | 593563002 | 1 | WSR 150 mm | ||
| 1SLURRY RINGS | 593563003 | 1 | WSR 200 mm | ||
| 1SLURRY RINGS | 593563004 | 1 | WSR 250 mm | ||
| 1SLURRY RINGS | 593563005 | 1 | WSR 300 mm | ||
| 1SLURRY RINGS | 593563006 | 1 | WSR 350 mm | ||
| 2SEALING DISCS | 593563401 | 1 | DS 100 mm | ||
| 2SEALING DISCS | 593563402 | 1 | DS 150 mm | ||
| 2SEALING DISCS | 593563403 | 1 | DS 200 mm | ||
| 2SEALING DISCS | 593563404 | 1 | DS 250 mm | ||
| 2SEALING DISCS | 593563405 | 1 | DS 300 mm | ||
| 2SEALING DISCS | 593563406 | 1 | DS 350 mm | ||
| 3SLURRY COLLECTOR | 531280329 | 1 | U-shap 212 mm | ||
| 4SLURRY COLLECTOR | 531280000 | 1 | 65 mm | ||
| 4SLURRY COLLECTOR | 531280001 | 1 | 110 mm | ||
| 4SLURRY COLLECTOR | 531280295 | 1 | 130 mm | ||
| 4SLURRY COLLECTOR | 531280002 | 1 | 160 mm | ||
| 4SLURRY COLLECTOR | 531280296 | 1 | 180 mm | ||
| 4SLURRY COLLECTOR | 531280003 | 1 | 210 mm | ||
| 4SLURRY COLLECTOR | 531074682 | 1 | 220 mm | ||
| 4SLURRY COLLECTOR | 531280004 | 1 | 260 mm | ||
| 4SLURRY COLLECTOR | 531280005 | 1 | 310 mm | ||
| 4SLURRY COLLECTOR | 531280006 | 1 | 360 mm | ||
| 5SLURRY COLLECTOR | 531074622 | 1 | V-shape 350 mm |
Regular price
$679.00
Regular price
|
|
| 5SLURRY COLLECTOR | 531280007 | 1 | V-shape 700 mm | ||
| 5SLURRY COLLECTOR | 531280322 | 1 | 410 mm | ||
| 5SLURRY COLLECTOR | 531074678 | 1 | 430 mm | ||
| 6COLLECTOR | 531077100 | 1 | |||
| 7RUBBER SEAL SET | 593963901 | 1 | WSR 100 | ||
| 7RUBBER SEAL SET | 593963902 | 1 | WSR 150 | ||
| 7RUBBER SEAL SET | 593963903 | 1 | WSR 200 | ||
| 7RUBBER SEAL SET | 593963904 | 1 | WSR 250 | ||
| 7RUBBER SEAL SET | 593963905 | 1 | WSR 300 | ||
| 7RUBBER SEAL SET | 593963906 | 1 | WSR 350 | ||
| 8TOOL | 531074688 | 1 | 1/2" | ||
| 8TOOL | 531074674 | 1 | 1 1/4" | ||
| 8TOOL | 531072003 | 1 | CR1 28 |
ACCESSORIES 5 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1START DEVICE | 522935001 | 1 | |||
| 2BRACKET | 504098701 | 1 | DM 200, DM 230 | ||
| 3KEY | 531140952 | 1 | DM 220 |
Regular price
$44.29
Regular price
|
|
| 4SCREW | 542139768 | 1 | DM 220 | ||
| 5HANDLE | 576024901 | 1 | DM 220 |
DECALS 5 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1DECAL | 529469601 | 1 | Gear instruction | ||
| 2DECAL | 529571301 | 1 | EU/RoW | ||
| 3DECAL | 529469701 | 1 | |||
| 4DECAL | 529469401 | 1 | With Bluetooth | ||
| 4DECAL | 529469402 | 1 | W/O Bluetooth |
ELECTRICAL 6 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1CONTROL PANEL | 599353601 | 1 | w/o Bluetooth | ||
| 1CONTROL PANEL | 599353501 | 1 | With Bluetooth |
Regular price
$113.49
Regular price
|
|
| 2WIRING ASSY | 599337501 | 1 |
Regular price
$47.19
Regular price
|
||
| 3WIRING ASSY | 529790601 | 1 |
Regular price
$73.09
Regular price
|
||
| 5CONTROL UNIT | 529588302 | 1 |
Regular price
$266.99
Regular price
|
||
| 7SCREW ITXSCFM | 525755111 | 1 |
GEAR BOX 42 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1SPINDLE SHAFT | 599769901 | 1 | ASSY 1 1/4" UNC |
Regular price
$471.59
Regular price
|
|
| 1SPINDLE SHAFT | 599769903 | 1 | ASSY 32/28.9 Japan |
Regular price
$1,715.99
Regular price
|
|
| 2PARALLEL KEY | 599772401 | 1 | A5x5x30 |
Regular price
$4.65
Regular price
|
|
| 3RETAINER RING | 543052745 | 1 |
Regular price
$3.25
Regular price
|
||
| 4BALL BEARING | 543052786 | 1 |
Regular price
$30.54
Regular price
|
||
| 5NUT | 504023401 | 1 |
Regular price
$7.99
Regular price
|
||
| 6CLAMPING SLEEVE | 582062601 | 1 | |||
| 7WASHER | 504027701 | 1 |
Regular price
$6.68
Regular price
|
||
| 8WASHER | 543052716 | 1 |
Regular price
$2.00
Regular price
|
||
| 9SPACER | 588926402 | 1 |
Regular price
$24.49
Regular price
|
||
| 10HANDLE | 574169401 | 1 | |||
| 11SCREW EHHM | 725251151 | 1 |
Regular price
$2.61
Regular price
|
||
| 12LID | 536808301 | 1 | |||
| 13RETAINER RING | 543052750 | 1 | |||
| 14RETAINER RING | 543052744 | 1 | |||
| 15SEAL | 543052771 | 2 |
Regular price
$13.79
Regular price
|
||
| 16SLEEVE | 599771801 | 2 |
Regular price
$94.50
Regular price
|
||
| 17BUSHING | 543052923 | 1 | |||
| 18O-RING | 599772301 | 2 | RDR47x1,5 |
Regular price
$3.66
Regular price
|
|
| 19BUSHING | 543052924 | 1 | |||
| 20GEAR HOUSING | 534190201 | 1 |
Regular price
$256.38
Regular price
|
||
| 21SCREW | 534137201 | 1 | M5x40 | ||
| 22SCREW | 534137301 | 3 | M5x20 | ||
| 23LEVER | 599769801 | 1 | GEARSHIFT |
Regular price
$131.25
Regular price
|
|
| 24PIN | 543052732 | 1 | |||
| 25SCREW | 543052661 | 1 | |||
| 26WASHER | 543052711 | 5 | |||
| 27GEARSHIFT LEVER | 599769701 | 1 |
Regular price
$464.29
Regular price
|
||
| 28O-RING | 598731901 | 1 |
Regular price
$4.73
Regular price
|
||
| 29PIN | 543052730 | 1 | |||
| 30HANDLE SUPPORT ASSY | 590869702 | 1 |
Regular price
$79.99
Regular price
|
||
| 31NUT | 501558001 | 1 | |||
| 32O-RING | 502496504 | 1 | |||
| 33HOSE ASSY | 501072201 | 1 |
Regular price
$92.80
Regular price
|
||
| 34HOSE CLAMP | 576129701 | 2 |
Regular price
$6.10
Regular price
|
||
| 35HOSE | 581893601 | 1 |
Regular price
$19.79
Regular price
|
||
| 36VALVE ASSY | 587437802 | 1 | |||
| 37O-RING | 505103501 | 1 |
Regular price
$6.10
Regular price
|
||
| 38STRAINER | 589780701 | 1 |
Regular price
$5.89
Regular price
|
||
| 39COUPLER | 503266004 | 1 | ROW |
Regular price
$9.39
Regular price
|
|
| 39COUPLER | 503266003 | 1 | US |
Regular price
$8.39
Regular price
|
|
| 40VACUUM SYSTEM | 575872201 | 1 |
MOTOR 13 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1MOTOR ASSY | 534113201 | 1 | INCL PINION |
Regular price
$567.00
Regular price
|
|
| 2PARALLEL PIN | 534150201 | 2 | 4m6x12 | ||
| 3O-RING | 543052780 | 1 |
Regular price
$4.55
Regular price
|
||
| 4NEEDLE BEARING | 543052791 | 2 |
Regular price
$15.14
Regular price
|
||
| 5HEXAGON NUT | 543052706 | 1 | |||
| 6GEAR WHEEL | 534113501 | 1 | CLUTCH | ||
| 7GEAR WHEEL SHAFT | 534113401 | 1 | |||
| 8BALL BEARING | 543052789 | 1 | |||
| 9RETAINER RING | 599773101 | 1 | AV18 |
Regular price
$14.89
Regular price
|
|
| 10GEAR WHEEL | 534113301 | 1 | |||
| 11SEAL | 543052769 | 1 |
Regular price
$13.65
Regular price
|
||
| 12CLUTCH ASSY | 534113801 | 1 | SLIP CLUTCH KIT |
Regular price
$63.19
Regular price
|
|
| 13FAN | 599254801 | 1 |
Regular price
$24.49
Regular price
|
REAR HANDLE 15 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1HANDLE HALF | 599254102 | 1 |
Regular price
$41.30
Regular price
|
||
| 2AIR INTAKE | 599722901 | 1 | |||
| 3TRIGGER | 599254301 | 1 | |||
| 4SPRING | 599254501 | 1 | |||
| 5SCREW ITXSCT | 580292901 | 9 |
Regular price
$1.56
Regular price
|
||
| 6SKID PLATE | 534113601 | 1 | |||
| 7DECAL | 529469701 | 1 | |||
| 8HANDLE HALF | 534113703 | 1 | With Bluetooth |
Regular price
$78.23
Regular price
|
|
| 8HANDLE HALF | 534113704 | 1 | w/o Bluetooth |
Regular price
$78.23
Regular price
|
|
| 9E-CLIP | 735310720 | 1 | |||
| 10SPRING | 599734601 | 1 | |||
| 11TRIGGER | 599719301 | 1 | |||
| 12AIR INTAKE | 599474001 | 1 | |||
| 13SPRING | 585480001 | 1 |
Regular price
$5.69
Regular price
|
||
| 14PUSH BUTTON | 577996601 | 1 |
Regular price
$5.60
Regular price
|
