Product Specification
General
Power Specifications
Working Specifications
Weight Specifications
Other Specifications
Warranty
Service & Maintenance Parts
12 MONTHS / 200 HOURS SERVICE KIT 4 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1SERVICE KIT | 548482001 | 1 | |||
| 2AIR FILTER | 594302101 | 1 | |||
| 3V-BELT | 594299001 | 1 | |||
| 4SPARK PLUG | 595051301 | 1 |
BASE PLATE 36 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1PLATE | 595052401 | 1 | |||
| 2WASHER | 594157001 | 5 |
Regular price
$6.68
Regular price
|
||
| 3BUSHING | 594156801 | 6 |
Regular price
$6.10
Regular price
|
||
| 4SPACER | 594156901 | 6 | |||
| 5WASHER | 594514801 | 3 | |||
| 6BOLT | 594119301 | 3 | M12x60 mm 8.8 A3K | ||
| 7SPRING | 594346201 | 3 |
Regular price
$26.49
Regular price
|
||
| 8ENGINE | 594155701 | 1 | |||
| 9SCREW | 594157201 | 3 | |||
| 10WASHER | 595066801 | 3 | 13x24x2 mm 300 HV |
Regular price
$0.36
Regular price
|
|
| 11NUT | 595112701 | 3 |
Regular price
$0.55
Regular price
|
||
| 12ABSORBER | 594156701 | 1 | |||
| 13WASHER | 595066601 | 1 | 8.4x 6x1.5 mm 300HV |
Regular price
$0.21
Regular price
|
|
| 14NUT | 595352301 | 1 | M8 |
Regular price
$0.29
Regular price
|
|
| 15WASHER | 595067601 | 3 | 10.5x28x6 mm |
Regular price
$1.36
Regular price
|
|
| 16ENGINE PLATE | 595453401 | 1 | |||
| 17WASHER | 595066701 | 3 |
Regular price
$0.29
Regular price
|
||
| 18SCREW | 595071101 | 3 |
Regular price
$0.51
Regular price
|
||
| 19WASHER | 595466901 | 1 | 14 x 40 x 4 mm, 0.55 x 1.57 x 0.16 | ||
| 20BRACKET | 594157101 | 1 |
Regular price
$44.19
Regular price
|
||
| 21BRACKET | 594156601 | 2 |
Regular price
$17.59
Regular price
|
||
| 22STRAP | 594155801 | 3 |
Regular price
$5.72
Regular price
|
||
| 23WASHER | 595067401 | 3 | 10.5x22x4 mm 300 HV | ||
| 24SCREW | 595054401 | 3 | M10x30 |
Regular price
$7.99
Regular price
|
|
| 25WASHER | 595112901 | 4 | 8.4x26x4 mm 300 HV |
Regular price
$5.34
Regular price
|
|
| 26SCREW | 596889707 | 4 |
Regular price
$0.21
Regular price
|
||
| 27SCREW | 595055401 | 3 | M8x20 mm 8.8 A2K | ||
| 28ABSORBER | 594429001 | 3 |
Regular price
$4.03
Regular price
|
||
| 29HANDLE | 594174601 | 1 |
Regular price
$130.19
Regular price
|
||
| 30BELT GUARD | 594960901 | 1 | |||
| 31GUARD | 594345201 | 1 | |||
| 32LOCK NUT | 594123001 | 4 | M8x1.25 mm A2K |
Regular price
$0.55
Regular price
|
|
| 33SHROUD | 594157501 | 1 | |||
| 34WASHER | 595189101 | 6 | 5x19x1 mm Expired/Eliminated | ||
| 35RIVET | 595187701 | 6 | |||
| 36ABSORBER | 594157301 | 1 |
CENTRIFUGAL CLUTCH 14 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1CENTRIFUGAL CLUTCH | 594156501 | 1 | |||
| 2SCREW | 595059301 | 2 | |||
| 3CLUTCH COVER | 594147601 | 1 | |||
| 4SPRING | 594583601 | 4 | |||
| 5CLUTCH | 595453201 | 2 | |||
| 6CLUTCH | 594147701 | 2 | |||
| 7CLUTCH | 595159901 | 1 | |||
| 8COVER | 594313101 | 1 | |||
| 9RING | 594308801 | 1 | |||
| 10RING | 594584401 | 1 | |||
| 11RING | 594584501 | 2 | |||
| 12BALL BEARING | 594584301 | 1 | |||
| 13RING | 594263701 | 1 | |||
| 14PULLEY | 594580401 | 1 |
DECALS 8 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1DECAL | 596280201 | 1 | DECAL Compliance RCM |
Regular price
$3.60
Regular price
|
|
| 2DECAL | 594536401 | 3 | |||
| 3DECAL | 594340901 | 1 | |||
| 4DECAL | 595464401 | 1 | Petrol, ear protection, read instruction manual, crush zone and hot surface. | ||
| 5DECAL | 595051201 | 1 |
Regular price
$1.36
Regular price
|
||
| 6DECAL | 594515501 | 1 | |||
| 7DECAL | 595096701 | 1 | |||
| 8DECAL | 577469001 | 1 |
ECCENTRIC ELEMENT 13 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1CLAMPING SLEEVE | 594156201 | 1 | |||
| 5PULLEY | 594156401 | 1 | |||
| 6SCREW | 595348001 | 8 | M6 x 20 mm 8.8 A2K | ||
| 7COVER | 595122001 | 1 | |||
| 8SEALING RING | 595044601 | 1 | |||
| 9BALL BEARING | 594156101 | 2 | |||
| 10COVER | 595121901 | 1 | |||
| 11SHAFT | 594156301 | 1 | |||
| 12SCREW | 595070501 | 1 | M16 x 75 mm 10.9 GEOMET® | ||
| 13WASHER | 595067501 | 5 | 17 x 30 x 6 mm, 0.70 x 1.18 x 0.24 in. 300 HV | ||
| 14SCREW | 595070301 | 2 | M16 x 65 mm 10.9 GEOMET® | ||
| 15WASHER | 595122101 | 1 | |||
| 16ECCENTRIC | 595121801 | 1 |
ECCENTRIC ELEMENT REPAIR KIT 5 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1REPAIR KIT | 594197201 | 1 | |||
| 2CLAMPING SLEEVE | 594156201 | 1 | |||
| 3SEALING RING | 595044601 | 1 | |||
| 4BALL BEARING | 594156101 | 2 | |||
| 5SCREW | 595348001 | 8 | M6x20 mm 8.8 A2K |
ENGINE 28 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1ENGINE | 594329901 | 1 | Honda GX160UT2 SXS4 SD | ||
| 2INLET SILENCER | 594203601 | 1 |
Regular price
$242.79
Regular price
|
||
| 3GASKET | 594204101 | 1 |
Regular price
$24.49
Regular price
|
||
| 4GASKET | 594300401 | 1 |
Regular price
$11.49
Regular price
|
||
| 5SPARK PLUG | 594204001 | 1 | (bpr6es) (ngk) | ||
| 6OIL | 594203801 | 1 |
Regular price
$21.61
Regular price
|
||
| 7GASKET | 594203901 | 1 | |||
| 8COVER | 595471101 | 1 | |||
| 9GASKET | 595048801 | 1 |
Regular price
$7.99
Regular price
|
||
| 10FUEL CAP | 594204601 | 1 |
Regular price
$45.89
Regular price
|
||
| 11FUEL TANK | 594204501 | 1 |
Regular price
$346.09
Regular price
|
||
| 12STOP | 594204401 | 1 |
Regular price
$104.19
Regular price
|
||
| 13PLUG | 595452801 | 1 | |||
| 14GASKET | 595048901 | 1 | |||
| 16GASKET | 594572601 | 1 |
Regular price
$5.34
Regular price
|
||
| 17CARBURETTOR | 594203701 | 1 |
Regular price
$480.38
Regular price
|
||
| 18SPACER | 595070001 | 1 |
Regular price
$32.29
Regular price
|
||
| 19NUT | 595049301 | 1 |
Regular price
$5.34
Regular price
|
||
| 20COVER | 595049201 | 1 |
Regular price
$74.79
Regular price
|
||
| 21NUT | 595049301 | 1 |
Regular price
$5.34
Regular price
|
||
| 22GASKET | 595049401 | 1 |
Regular price
$10.29
Regular price
|
||
| 23AIR FILTER | 594302101 | 1 | Delivered with outer and inner filter. |
Regular price
$53.38
Regular price
|
|
| 24ADAPTER | 594582401 | 1 |
Regular price
$124.25
Regular price
|
||
| 25MUFFLER COVER | 594300201 | 1 |
Regular price
$140.00
Regular price
|
||
| 26STARTER | 594300601 | 1 | Valid up to engine serial number 1411005, Red |
Regular price
$409.39
Regular price
|
|
| 36ROPE | 595049101 | 1 |
Regular price
$39.69
Regular price
|
||
| 37STARTER | 594204801 | 1 | recoil "nh1", Valid from engine serial number 1411006, Black |
Regular price
$269.79
Regular price
|
|
| 47ROPE | 595049101 | 1 |
Regular price
$39.69
Regular price
|
ENGINE INSTALLATION 21 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1ENGINE | 594329901 | 1 | Honda GX160UT2 SXS4 SD | ||
| 2WASHER | 595036601 | 4 | 8.4 x 16 x 1.5 mm, 0.33 x 0.63 x 0.06 in. 300 HV | ||
| 3NUT | 595352301 | 4 | M8 | ||
| 5WASHER | 595067001 | 1 | 21 x 36 x 3 mm, 0.83 x 1.42 x 0.24 in. 300 HV | ||
| 6WASHER | 595112901 | 1 | 8.4 x 26 x 4 mm, 0.33 x 1.02 x 0.16 in. 300 HV | ||
| 7SCREW | 594117901 | 1 | M8 x 20 mm 8.8 A2K | ||
| 8V-BELT | 594299001 | 1 | |||
| 9WASHER | 595290301 | 1 | 10 x 14 x 1 mm, 0.39 x 0.55 x 0.04 in. | ||
| 10HOSE CONNECTOR | 594648201 | 1 | |||
| 11CLAMP | 595454601 | 2 | 11-18 x 9 mm, 0.43 -0.71 x 0.35 in. | ||
| 12HOSE | 594147801 | 1 | |||
| 13CLIP | 594331001 | 1 | |||
| 14SCREW | 595033201 | 1 | M6x16 | ||
| 15PLUG | 594147301 | 1 | |||
| 16SCREW | 595055701 | 4 | M8 x 55 mm 8.8 A2K | ||
| 17WASHER | 594501601 | 4 | 9 x 35 x 2 mm, 0.35 x 1.38 x 0.08 in. SR | ||
| 18WASHER | 594157401 | 4 | |||
| 19COVER | 595213101 | 1 | |||
| 20WASHER | 595043901 | 7 | 8 x 13.5 mm, 0.53 x 0.31 x in. NORD-LOCK® | ||
| 21SCREW | 594120001 | 1 | M8 x 25 mm 8.8 A2K | ||
| 22SCREW | 595287101 | 3 | M8x50 |
SERVICE KIT 6 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1SERVICE KIT | 594200201 | 1 | |||
| 2AIR FILTER | 594302101 | 1 | |||
| 3GASKET | 595048901 | 1 | |||
| 4ROPE | 595049101 | 1 | |||
| 5SPARK PLUG | 594544301 | 1 | |||
| 6GASKET | 595048801 | 1 |
SHOCK ABSORBER REPAIR KIT 8 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1REPAIR KIT | 594197101 | 1 | |||
| 2ABSORBER | 594156701 | 1 | |||
| 3ABSORBER | 594429001 | 3 | |||
| 4LOCK NUT | 594123001 | 1 | Nut M08x1,25, -8, A2K (lock nut) | ||
| 5SCREW | 596889707 | 3 | M8 x 12 mm 8.8 A2K | ||
| 6SCREW | 594117901 | 1 | M8 x 20 | ||
| 7WASHER | 595036601 | 4 | 8.4 x 16 x 1.5 mm, 0.33 x 0.63 x 0.06 in. 300 HV | ||
| 7WASHER | 595112901 | 3 | 8.4 x 26 x 4 mm, 0.33 x 1.02 x 0.16 in. 300 HV |
THROTTLE CONTROL 7 parts
| Part | Article number | Qty | Comment | Price | Details |
|---|---|---|---|---|---|
| 1THROTTLE CONTROL | 594341001 | 1 | |||
| 2MOUNT | 537565101 | 1 | |||
| 3LOCK NUT | 595187101 | 1 | |||
| 4SCREW | 537566001 | 1 | |||
| 5SCREW | 594399001 | 2 | |||
| 6SPRING | 594327701 | 1 | |||
| 7ADAPTER | 546299301 | 1 |
