Product Specifications
Specifications
Engine Power (As rated by the engine manufacturer)
                    20.5 hp
                  Cylinders
                    2
                  Number of strokes
                    4-stroke engine
                  Starter
                    Electric
                  Exhaust emissions (CO₂ EU V)
                    834 g/kWh
                  Power source
                    Petrol
                  Cutting depth, max
                    3 in
                  Blade diameter, max
                    13.5 in
                  Blade depth control
                    Electric
                  Type of operation
                    Self-propelled
                  Product size length
                    34 in
                  Product size height
                    34 in
                  Weight
                    454 lbs
                  Packaging length (Calc)
                    67.008 in
                  Packaging width (Calc)
                    35 in
                  Packaging height (Calc)
                    60 in
                  Article gross weight (Calc)
                    560.009 lbs
                  Document Downloads
Assembly instruction
Operator's manual
Service bulletin
-

                   SB. Actuator play in the axle, Soff-Cut 4000, 2022-04PDF EN
 -

                   SB. Battery Specifications for FS and Soff-Cut, 2015-06PDF EN
 -

                   SB, Engine Mount Kit, SoffCut 2000, 4000, 4200 and 5000, 2016-05PDF EN
 -

                   SB, SoffCut Press Pin , X2000, X2500, X4000, X4200, X5000, 2015-06PDF EN
 -

                   SB. Engine model information, FS, SoffCut, PP, 2016-03PDF EN
