Product Specifications
Specifications
Engine Power (As rated by the engine manufacturer)
                    23 hp
                  Cylinders
                    2
                  Number of strokes
                    4-stroke engine
                  Starter
                    Electric
                  Exhaust emissions (CO₂ EU V)
                    834 g/kWh
                  Power source
                    Petrol
                  Cutting depth, max
                    3 in
                  Blade diameter, max
                    13.5 in
                  Blade depth control
                    Electric
                  Type of operation
                    Self-propelled
                  Product size length
                    89 in
                  Product size height
                    40.25 in
                  Weight
                    472 lbs
                  Packaging length (Calc)
                    67.008 in
                  Packaging width (Calc)
                    35 in
                  Packaging height (Calc)
                    45 in
                  Article gross weight (Calc)
                    566.01 lbs
                  Document Downloads
Service bulletin
-

                   SB. Battery Specifications for FS and Soff-Cut, 2015-06PDF EN
 -

                   SB, SoffCut Press Pin , X2000, X2500, X4000, X4200, X5000, 2015-06PDF EN
 -

                   SB, Engine Mount Kit, SoffCut 2000, 4000, 4200 and 5000, 2016-05PDF EN
 -

                   SB. Engine model information, FS, SoffCut, PP, 2016-03PDF EN
 -

                   SB, Updated fuel tank, Soff-Cut 4200, Soff-Cut 5000, 2021-06PDF EN
